Glass, Cements, Ceramics and Metals

Negoo Group

Mixing & Dispending Technologies

Negoo Group mixers, blenders and dispersers are used throughout the ceramic manufacturing industry. Applications include the simple blending of dry powders to the sophisticated dispersion of solids into high viscosity fluids

OVERVIEW

The rapid development of technical ceramics and ceramic-based composites is pushing manufacturers to seek new and improved methods of production. Mixing has a direct correlation to the performance, strength, and durability of specialty ceramics and composites. Different products vary in the ways they are handled, formed and finished, but at the heart of the process is the mixing procedure, which commonly takes place in planetary-style mixers.

Known worldwide for heavy-duty, robust construction, superior design, high-quality materials, and fine craftsmanship, the complete line of Negoo Group’s Planetary Mixers and Vacuum Blender/Dryers are widely used in the manufacture of glass, ceramics, and metal applications.

PRODUCT APPLICATIONS

Ceramic Formulations – Metal or ceramic Injection molding is a process used for forming intricate parts in a wide variety of alloys, steels, carbides and ceramic compounds. The process begins by making a mixture of a desired metal or ceramic powder with a binding agent such as a polymer, wax or resin. The resulting mixture is usually a viscous paste at elevated temperatures that will solidify when cooled. This metal or ceramic paste is injected into a mold where it takes a desired shape before being ejected. The binder is carefully stripped off from the part, leaving a skeleton of metal or ceramic powder which is then heated to melt strong bonds between adjacent particles. The accuracy and strength of injection molded pieces rely on the quality of the molding compound mixture. If dispersion quality is poor, the resulting part could be warped, weak or not formed correctly. Negoo Group Planetary Mixers are highly successful at producing good dispersions with high viscosity, high density molding compounds. Heat is evenly applied to these compounds by hot oil recirculating through the jacketed mix can.

Energetics and Propellants – Negoo Group Planetary Mixers and Vertical Blenders are popular choices for mixing and drying of energetics and propellant formulations. Discharge is fairly simple on the V-Blender as it is designed for complete discharge. Negoo Group offers features such as solvent-resistant elastomers, lock-wired hardware in the product zone, tight clearances between stirrers and mix can, elaborate explosion-proof local and remote PLC controls, intrinsically safe vacuum/pressure transducer, grounding straps and explosion-proof camera and light assembly, among others.

Enamel and Enamel Mediums – Used for decorating of ceramics and glass products and for automotive glass applications. Traditional mixing utilizes single shaft Cowles blades or combinations of dispersers and anchors. Due to difficulty encountered in achieving the proper dispersion in a reasonable amount of time, Negoo Group customers tried the PowerMix and found very good results.

Epoxy and Glass Bead Molding Compounds – Epoxy and glass spheres are easily mixed and dried in a Negoo Group Double Planetary Mixer. These compounds are used for a variety of vacuum form molds.

Glass Powder Compounds – Free-flowing glass powders, colorants and solid wax polymers are heated and mixed in a jacketed Negoo Group Double Planetary Mixer. The dry blend is ultimately mixed into a binder and pressed to form a solid glass body. In the dry batching process of fine glassware, the advantages of using a Negoo Group Ribbon Blender manifest in fast mixing, low head room and dust-tight construction (or vacuum, if required).

Molten Metal Slurries – Negoo Group is a reliable supplier to major players in the metals industry, many of whom demand very special mixer features for their sensitive products. One such application is the processing of molten metals which required temperatures upwards of 350F, double mechanicals seals for all agitators with complete seal support system, extra head space in the mix can, interchangeable dispersers and rotor/stators and Type Z gas-purged control panel.

Brazing Slurries – Aluminum, copper, silver, nickel and other alloy-based brazing and soldering pastes are used in the metal and electronics industries. Customers formerly using single planetary mixers to mix the powder metals and vehicles noticed a tremendous amount of air incorporated into each batch. This air can manifest in voids in the finished filled syringes that are used in the application of brazing and soldering pastes. Vacuum-rated Negoo Group Double and Hybrid Planetary Mixers are proven more successful at making void-free product and also at processing the binders that are later used in the manufacture of metal pastes and brazing materials. Negoo Group Discharge Systems are also appropriate for clean and quick extrusion of these products after vacuum mixing.

Tungsten Carbide Powders – The Negoo Group Double Planetary Mixer is extremely successful in blending a slurry of these extremely dense materials, then vacuum drying the batch to form a light, fluffy powder.

Water-based Castable Cements – Used in the glass and aluminum casting industries. Negoo Group Planetary Vacuum Mixers produce high quality cements with zero porosity.

Powdered Metals and Alloys – Negoo Group Tumble Blenders are well proven for high-density metal and alloy powder blends used in 3D printing and other applications. Heavy-duty designs capable of handling up to 900 lbs/cu.ft. are available.

Customer Support

To schedule a field service visit by a Negoo Group’s technician, please contact us to arrange a visit. All Negoo Group’s service visits are performed by technicians from our manufacture.
